Electrochemical characterization tool selector
|Nano-Manipulator||Biasing TEM||Tomography TEM||Liquid TEM||Gas TEM||Liquid X-Ray||Liquid SEM|
|Battery Configuration||Individual nanowire/nanoparticle|
|Imaging||Higher resolution and diffraction|
|Pre-and post-mortem analysis|
|Transfer air-sensitive samples|
|Beam Effects||Compatibility with volatile electrolytes|
|Minimal beam damage|
|Quantitative Electrochemistry||Replicate bulk measurements|
|Image all battery components|
Excellent Good N/A
Site-Specific Nano-Probing and Biasing
Hummingbird Scientific’s in-situ nano-manipulator probe can selectively charge or discharge individual nanomaterials such as nanowires and nanoparticles. This is a great tool for studying mechanics and kinetics of individual nanostructures, while allowing to manipulate and characterize their behavior in real-time. The piezo-driven probe carries the charge source (e.g. Li, Na, Mg or ionic liquid electrolyte). The sample containing TEM specimen is mounted to the fixed stage. A negative/positive bias is applied to the sample with respect to the probe source to initiate the reaction and study site-specific connections between material microstructure and performance.
The image on the left shows the lithiation/delithiation behavior of porous silicon nanorods, in which the void space allows free volumetric expansion during lithium intercalation and deintercalation processes.
Reference: Z. Yang, J. Sun, Y. Nia, Z. Zhao, J. Bao, S. Chen. “Facile synthesis and in situ transmission electron microscopy investigation of a highly stable Sb2Te3/C nanocomposite for sodium-ion batteries,” Energy Storage Materials 9 (2017) pp. 214-220. Abstract
Copyright © 2017 American Chemical SocietyEdit
Electrochemistry Suite Biasing
Hummingbird Scientific’s in-situ electrical biasing holder can be used for electrochemically cycling thin film batteries while imaging the material microstructure. Representative battery cell can be thinned using FIB processing or glued to the substrate. The sample is a representative section of the real battery cell and the data obtained is representative of the real battery performance.
For example, a thin cross-section of a battery cell can be mounted, wire-bonded, and viewed in TEM while cycling. The image shown on the left is a 10 nm graphite flake folded onto itself after one complete intercalation/deintercalation cycle.
Reference: Edward R. White, Jared J. Lodico & B. C. Regan. “Intercalation events visualized in single microcrystals of graphite,” Nature Communications 8 (2017) pp. 1969. Abstract
Image (left) © 2017 Macmillan Publishers Limited, part of Springer Nature
Image (bottom right) © Materials Research Society 2010
Hummingbird Scientific’s Tomography holder is an important characterization tool in the electrochemistry suite that allows to perform pre or post-mortem analyses of battery materials in great details. Because the system permits unusually high tilt angles, the sample itself is the only contributor to the missing wedge. A range of removable tips are available for the system and can be customized for specific specimen support geometries. Specifically, any cycled samples on chips from the in-situ liquid/gas cell holders can be easily transferred and placed in the dedicated Tomography tip for analyses.
Image on the left shows the porosity of silicon structure evaluated for battery materials.
Reference: M. Ge, Y. Lu, P. Ercius, J. Rong, X. Fang, M. Mecklenburg, and C. Zhou “Large-Scale Fabrication, 3D Tomography, and Lithium-Ion Battery Application of Porous Silicon” Nano Letters 14 (2014) pp. 261–268. Abstract
Image copyright © 2016 American Chemical SocietyEdit
Hummingbird Scientific’s in-situ liquid holder allows researchers to image systems with volatile electrolytes enclosed in a cell in TEM. The flexibility of using any standard liquid electrolytes allows for the opportunity to mimic true electrochemistry in TEM. However, there are challenges associated with optimizing hardware suitable for small volume and limited diffusion cell geometries of liquid cell system. Our newest Generation V liquid cell system has the capability to observe and measure full-cycle bulk-level electroanalytical data in-situ in the TEM.
The image on the top left shows an example of cyclic voltammetry curve obtained during the copper deposition/stripping cycle in liquid cell TEM. This curve obtained in the liquid TEM cell mimics the bulk data from the large volumetric cell exactly and therefore can be used as a representative characterization tool of the relevant chemistries.Edit
TEM Sample Transfer and Biasing in Gas
Hummingbird Scientific’s in-situ Gas cell holders can be used as biasing holders of samples in gas environments that also allow encapsulation and transfer of air-sensitive battery materials with an inert gas from the glovebox to the TEM. Thin film battery materials can be loaded in the gas holder in the glove box and moved to the TEM in fully protected environmental conditions. The inlet and outlet are capped airtight enabling sample transfer to the TEM without exposure in air. Electrical biasing experiments can be conducted in-situ in the TEM in this protective environment or other relevant environmental conditions can be created around the sample by flowing in the relevant gas.
The TEM image of the top left shows the atomic scale redox dynamics of Ag/AgCl heterostructures studied using in-situ TEM gas holder.
Reference: Yimin A. Wu, Liang Li, Zheng Li, Alper Kinaci, Maria K. Y. Chan, Yugang Sun, Jeffrey R. Guest, Ian McNulty, Tijana Rajh, and Yuzi Liu. “Visualizing Redox Dynamics of a Single Ag/AgCl Heterogeneous Nanocatalyst at Atomic Resolution,” ACS Nano (2016) pp. 3738-3746. Abstract
Image copyright © 2016 American Chemical SocietyEdit
Our TEM liquid holder is compatible with most Synchrotron X-Ray and SEM liquid-cell options. Common options include:
- Continuous Flow
- Dual Flow/Mixing
- Static Cell
- Vapor System
Don’t see what you’re looking for? We would also be happy to develop a custom solution for you.Edit
Multi-Modal Liquid X-Ray Microscopy
Designed for x-ray microscopes and synchrotron beamlines, Hummingbird Scientific’s x-ray environmental cell systems use the same removable tip design of our liquid TEM holder, allowing for multi-modal electrochemistry experiments across x-ray and electron microscope platforms
Using the operando x-ray microscopy platform shown here, William Chueh and team mapped the dynamics of the Li composition and insertion rate in LixFePO4, and found that nanoscale spatial variations in rate and in composition control the lithiation pathway at the subparticle length scale.
Reference: J. Lim,Y. Li, D. H. Alsem, H. So, S. C. Lee, P. Bai, D.A. Cogswell, X. Liu, N. Jin, Y. Yu, N. J. Salmon, D. A. Shapiro, M. Z. Bazant, T.Tyliszczak, W. C. Chueh, “Origin and Hysteresis of Lithium Compositional Spatiodynamics Within Battery Primary Particles,” Science 353 (2016) pp. 566-571. Abstract
Image copyright © 2016, American Association for the Advancement of ScienceEdit
We are proud to offer the Biologic SP-200/300 potentiostat as our recommended potentiostat for electrochemistry experiments. Hummingbird Scientific’s multi-modal set of electrochemistry charactierzation tools and Biologic’s potentiostat can be used in combination for corrosion experiments, electro-catalysis, electrolysis, and battery and photovoltaic research.Edit
Bulk Electrochemistry in TEM
Replicating bulk electrochemistry data in TEM
Hummingbird Scientific’s newest Generation V in-situ liquid-electrochemistry holder allows researchers for the first time to fully replicate bulk-level electrochemical details inside the transmission electron microscope. A newly developed hardware system allows quantitative measurements of electrochemical processes with details showing the complete cycle of the bulk.
As illustrated, a cyclic voltammetry (CV) study of a model compound 01.M copper sulfate showing plating and deposition of copper has been presented here. The copper deposition and stripping occurs at the Pt working electrode, largely mimicking bulk behavior.
The new Hummingbird Scientific’s liquid-cell hardware and cells allows for replications of bulk-level data in TEM.
|Chen Houa, Jiuhui Hanb, Pan Liua, Chuchu Yangb, Gang Huangb, Takeshi Fujitab, Akihiko Hiratab, and Mingwei Chen. “Operando observations of RuO2 catalyzed Li2O2 formation and decomposition in a Li-O2 micro-battery,” Nano Energy (2018)||Abstract|
|Pan Liu, Jiuhui Han, Xianwei Guo, Yoshikazu Ito, Chuchu Yang, Shoucong Ning, Takeshi Fujita, Akihiko Hirata and Mingwei Chen. “Operando characterization of cathodic reactions in a liquid-state lithium-oxygen micro-battery by scanning transmission electron microscopy,” Scientific Reports (2018)||Abstract|
|Jeung Hun Park, Nicholas M. Schneider, Daniel A. Steingart, Hariklia Deligianni, Suneel Kodambaka, and Frances M. Ross. “Control of Growth Front Evolution by Bi Additives during ZnAu Electrodeposition,” Nano Letters (2018)||Abstract|
|YuBo Wang, Shuai Wang, and Xing Lu. “In Situ Observation of the Growth of ZnO Nanostructures Using Liquid Cell Electron Microscopy,” The Journal of Physical Chemistry C (2017)||Abstract|
|Mingyuan Ge, Ming Lu, Yong Chu & Huolin Xin. “Anomalous Growth Rate of Ag Nanocrystals Revealed by in situ STEM,” Scientific Reports (2017)||Abstract|
|See Wee Chee, Shu Fen Tan, Zhaslan Baraissov, Michel Bosman & Utkur Mirsaidov. “Direct observation of the nanoscale Kirkendall effect during galvanic replacement reactions,” Nature Communications (2017)||Abstract|
|Eli Fahrenkrug, Daan Hein Alsem, Norman Salmon and Stephen Maldonado. “Electrochemical Measurements in In Situ TEM Experiments,” Journal of The Electrochemical Society (2017)||Abstract|
|Fei-Hu Du, Yizhou Ni, Ye Wang, Dong Wang, Qi Ge, Shuo Chen, and Hui Ying Yang. “Green Fabrication of Silkworm Cocoon-like Silicon-Based Composite for High-Performance Li-Ion Batteries,” ACS Nano (2017)||Abstract|
|Chuchu Yang, Jiuhui Han, Pan Liu, Chen Hou, Gang Huang, Takeshi Fujita, Akihiko Hirata, and Mingwei Chen. “Direct Observations of the Formation and Redox-Mediator-Assisted Decomposition of Li2O2 in a Liquid-Cell Li–O2 Microbattery by Scanning Transmission Electron Microscopy,” Advanced Materials (2017)||Abstract|
|Karalee Jarvis, Chih-Chieh Wang, María Varela, Raymond R. Unocic, Arumugam Manthiram, and Paulo J. Ferreira. “Surface Reconstruction in Li-rich Layered Oxides of Li-ion Batteries,” Chemsitry of Materials (2017)||Abstract|
|Edward R. White, Jared J. Lodico & B. C. Regan. “Intercalation events visualized in single microcrystals of graphite,” Nature Communications (2017)||Abstract|
|Jeung Hun Park, Daniel A. Steingart, Suneel Kodambaka, and Frances M. Ross. “Electrochemical electron beam lithography: Write, read, and erase metallic nanocrystals on demand,” Science Advances (2017)||Abstract|
|Timothy S. Arthur, Per-Anders Glans, Nikhilendra Singh, Oscar Tutusaus, Kaiqi Nie, Yi-Sheng Liu, Fuminori Mizuno, Jinghua Guo, Daan Hein Alsem, Norman J. Salmon, and Rana Mohtadi. “Interfacial insight from operando sXAS/TEM for magnesium metal deposition with borohydride electrolytes,” Chemistry of Materials (2017)||Abstract|
|J. Lim,Y. Li, D. H. Alsem, H. So, S. C. Lee, P. Bai, D.A. Cogswell, X. Liu, N. Jin, Y. Yu, N. J. Salmon, D. A. Shapiro, M. Z. Bazant, T.Tyliszczak, W. C. Chueh, “Origin and Hysteresis of Lithium Compositional Spatiodynamics Within Battery Primary Particles,” Science (2016)||Abstract|
|Yimin A. Wu, Liang Li, Zheng Li, Alper Kinaci, Maria K. Y. Chan, Yugang Sun, Jeffrey R. Guest, Ian McNulty, Tijana Rajh, and Yuzi Liu. “Visualizing Redox Dynamics of a Single Ag/AgCl Heterogeneous Nanocatalyst at Atomic Resolution,” ACS Nano (2016)||Abstract|
| J.H. Park, N.M. Schneider, J.M. Grogan, M.C. Reuter, H.H. Bau, S. Kodambaka & F.M. Ross, “Control of Electron Beam-Induced Au Nanocrystal Growth Kinetics
through Solution Chemistry,” Nano Letters (2015)
|Raymond R. Unocic, Loïc Baggetto, Gabriel M. Veith, Jeffery A. Aguiar, Kinga A. Unocic, Robert L. Sacci, Nancy J. Dudney and Karren L. More. “Probing battery chemistry with liquid cell electron energy loss spectroscopy,” Chemical Communications (2015)||Abstract|
|M. Ge, Y. Lu, P. Ercius, J. Rong, X. Fang, M. Mecklenburg, and C. Zhou “Large-Scale Fabrication, 3D Tomography, and Lithium-Ion Battery Application of Porous Silicon” Nano Letters (2014)||Abstract|
|R.L. Sacci, N. Dudney, K. More, L.R. Parent, I. Arslan, N.D. Browning, and R.R. Unocic. “Direct Visualization of Initial SEI Morphology and Growth Kinetics During Lithium Deposition by In-Situ Electrochemical Transmission Electron Microscopy,” Chemical Communication (2014)||Abstract|
|P. Abellan, B. L. Mehdi, L.R. Parent, M. Gu, C. Park, W. Xu, Y. Zhang, I. Arslan, J.G. Zhang, C.M. Wang, J.E. Evans, and N.D. Browning. “Probing the Degradation Mechanisms in Electrolyte Solutions for Li-Ion Batteries by in Situ Transmission Electron Microscopy,” Nano Letters (2014)||Abstract|
|M. Gu, L.R. Parent, B.L. Mehdi, R.R. Unocic, M.T. McDowell, R.L. Sacci, W. Xu, J.G. Connell, P. Xu, P. Abellan, X. Chen,Y. Zhang, D.E. Perea, J.E. Evans, L.J. Lauhon, J.G. Zhang, J. Liu, N.D. Browning, Y. Cui, I. Arslan, and C.M. Wang. “Demonstration of an Electrochemical Liquid Cell for Operando Transmission Electron Microscopy Observation of the Lithiation/Delithiation Behavior of Si Nanowire Battery Anodes.” Nano Letters (2013)||Abstract|
|E.R. White, S.B. Singer, V. Augustyn, W.A. Hubbard, M. Mecklenburg, B. Dunn, and B.C. Regan,“In-Situ Transmission Electron Microscopy of Lead Dendrites and Lead Ions in Aqueous Solution,” ACS Nano (2012)||Abstract|
|C.M. Wang, W. Xu, J. Liu, D.W. Choi, B. Arey, L.V. Saraf, J.G. Zhang, Z.G. Yang, S. Thevuthasan, D.R. Baer and N. Salmon. “In situ transmission electron microscopy and spectroscopy studies of interfaces in Li ion batteries: Challenges and opportunities,” Journal of Materials Research (2010)||Abstract|
